xStack® DGS-3120 Series Layer 2 Stackable Managed Switch Web UI Reference Guide

IGMP Multicast Group Profile Settings

Users can add a profile to which multicast address reports are to be received on specified ports on the Switch. This
function will therefore limit the number of reports received and the number of multicast groups configured on the Switch.
The user may set an IP Multicast address or range of IP Multicast addresses to accept reports (Permit) or deny reports
(Deny) coming into the specified switch ports.
To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > IGMP Multicast Group
Profile Settings, as show below:
The fields that can be configured are described below:
Parameter
Profile Name
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the View All button to display all the existing entries.
Click the Delete button to remove the corresponding entry.
Click the Group List link to configure the Multicast Group Profile Address Settings for the specific entry.
After clicking the Group List
Figure 4-63 Multicast Group Profile Multicast Address Settings window
The fields that can be configured are described below:
Parameter
Multicast Address List
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Figure 4-62 IGMP Multicast Group Profile Settings window
Description
Enter a name for the IP Multicast Profile.
link, the following page will appear:
Description
Enter the multicast address list value.
