Binding Settings Dialog Box

Binding Settings Dialog Box

This is displayed when you select Binding Settings from theEdit menu. This allows you to configure the binding edge
settings.
• Binding Edge
Configures the binding edge when folding paper.
The following settings are available for the binding edge.
Setting
Bottom
Top
• Binding
Configures the binding margin (gutter).
Prints by creating a binding margin (gutter) of the specified size. Enter the margin size as a number.
• The values that can be entered are 0 to 50 (mm).
Note
• Print Fold Lines
Configures the color and type of fold lines.
• To not print fold lines, clear the Print Fold Lines checkbox.
Note
• Fold Line Color
You can select the fold lines.
• Fold Line Type
You can select the fold lines.
The following settings are available for the fold line type.
Setting
Solid Line
Dotted Line
Dashed Line
• Only Print Center and Edges
To print fold lines at the center and both edges, select the Only Print Center and Edges checkbox.
User's Guide
Prints by placing the binding margin (gutter) at the bottom of the document.
Prints by placing the binding margin (gutter) at the top of the document.
You can print the solid line as the frame style.
You can print the dotted line as the frame style.
You can print the dashed line as the frame style.
Binding Settings Dialog Box
Details
Details
