Canon imagePROGRAF iPF8400S User Manual page 941

iPF8400S
5
Refer to the following table to confirm the number on
the Platen (a) that corresponds to the size of paper for
printing.
2
3
4
5
6
7
8
9
10
11
User's Guide
Number Dimensions
254.0 mm (10.00 in)
355.6 mm (14.00 in)
431.8 mm (17.00 in)
515.0 mm (JIS B2 or B3)
594.0 mm (ISO A1 or A2) or 609.6 mm (24.00 in)
841.0 mm (ISO A0 or A1)
914.4 mm (36.00 in)
1030.0 mm (JIS B0 or B1)
1066.8 mm (42.00 in)
1117.6 mm (44.00 in)
Setting the Blue Switch on the Platen
941
