Add Custom Paper
7
The Step 3: Paper Source Settings dialog box is displayed.
Select the paper source where the custom paper is loaded and
then click the OK button.
8
The Step 4: Paper feed adjustment dialog box is dis-
played. Click the Execute button to execute paper feed
adjustment.
The adjustment pattern is printed, and the paper feed is
automatically adjusted based on the printing result.
Once the paper feed adjustment is complete, click the
Next button.
Important
9
The Roll Paper Settings dialog box is displayed.
•
Note
Configure the following settings as necessary, and then click the Next button.
Automatic Cutting Settings
580
• Check that there is no paper left on the ejection guide.
• If Paper Feed Adjustment is not executed, horizontal stripes with different color tones may appear in the printed
material. Paper feed adjustment does not need to be executed more than once. Execute paper feed adjustment
only once each time you add a custom paper.
If a paper source other than Roll Paper is selected in the Step 3: Paper Source Settings dialog box, this screen is
not displayed.
Setting
Configures the method for cutting roll paper when it is ejected after printing.
•
Automatic Cut:Roll paper is automatically cut by the cutter unit.
•
Eject Cut:When the Cut key is pressed on the printer control panel, the roll paper is cut by
the cutter unit. Select this if you do not want the printed material to drop immediately after
printing, such as to wait for the ink to dry.
Details
