iPF8400S
Setting Item
Air Drying
Position of Ventilation Fan
8
The View Settings window is displayed. Check the de-
tails of the settings and click the OK button.
• Click the Add to Favorites button to display the Add to Favorites dialog box, which allows you to add the setting
details to favorites.
Note
9
The Output Color Measurement Data dialog box is
displayed.
Select the file to save the color measurement data into
and click the OK button.
10
The Acquire Color Measurement Data dialog box is
displayed.
Click the Execute button.
User's Guide
If the Dry Separated Chart check box is clear, printing and air drying the color chart are per-
formed once. This reduces the time taken by the operation, but may scratch or soil the end of
the color chart and paper. However, this does not affect the color measurement results.
If you are using paper that has a tendency to curl or paper that does not dry easily, select High
so that the paper does not come into contact with the paper presser.
Note that when High is selected, we recommend that you set the Time longer and the Airflow
stronger compared with when Standard is selected because of the larger distance between the
ventilation fan and paper.
Acquiring Color Measurement Data For Any Color Chart
Details
