Configuring the Communication Mode Manually

7
Click OK to activate the settings.
Configuring the Communication Mode Manually
Configuring the Communication Mode Manually
This topic gives instructions for configuring the communication mode manually.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
•
Note
2
Press the OK button.
The Set./Adj. Menu is displayed.
3
Press ▲ or ▼ to select Interface Setup, and then press the OK button.
4
Press ▲ or ▼ to select Ethernet Driver, and then press the OK button.
5
Press ▲ or ▼ to select Auto Detect, and then press the OK button.
6
Press ▲ or ▼ to select Off, and then press the OK button.
The display reverts to the Ethernet Driver menu.
7
Press ▲ or ▼ to select Comm.Mode, and then press the OK button.
8
Press ▲ or ▼ to select the communication mode, and then press the OK button.
The display reverts to the Ethernet Driver menu.
9
Press ▲ or ▼ to select Ethernet Type, and then press the OK button.
10
Press ▲ or ▼ to select the Ethernet type, and then press the OK button.
The display reverts to the Ethernet Driver menu.
11
Press ▲ or ▼ to select Spanning Tree, and then press the OK button.
12
Press ▲ or ▼ to enable or disable spanning tree support, and then press the OK button.
The display reverts to the Ethernet Driver menu.
13
Press the Menu button.
After the confirmation message is displayed, press the OK
button.
The new settings will take effect after the printer restarts.
698
).
If the Tab Selection screen is not displayed, press the Menu button.
