Color Measurement Sheet
For the procedure for configuring color check scheduler settings, see "Scheduling Color Check."
• Color Measure button
Click this button to display the procedure description window or Select Execution Log window.
This allows you to measure the colors of a color chart in the selected printer and acquire the color measurement
data.
For the procedure for acquiring color measurement data, see "Acquiring Color Measurement Data For Any Color
Chart."
P.821
➔
• The printer driver needs to be installed in order to acquire color measurement data.
Select a printer that uses the printer driver in the Printer list and acquire the color measurement data.
Important
• Color Check button
Click this button to display the Execute Color Check dialog box.
Execute color check on the selected printer.
For the procedure for executing color check, see "Executing Color Check."
• Execution Logs
Displays the execution logs of acquiring color measurement data.
is displayed on the paper being fed.
The name registered in the favorites is displayed in Name.
• Save Data button
Click this button to display the Output Color Measurement Data dialog box.
This saves the color measurement data from the selected execution log on the computer.
• Favorites button
Click this button to display the Favorites Management dialog box.
This allows you to check the execution logs registered in the favorites.
• Log Details button
Click this button to display the Execution Log Details dialog box.
814
This allows you to check the details of the selected execution log.
