Canon imagePROGRAF iPF8400S User Manual page 106

Printing on Non-Standard Paper Sizes (Windows)
Once you register Custom Paper Size, you then can select it repeatedly from the paper size list.
Custom Paper Size can be set up to 18.0 m.
• Although you also can set Custom Size for the paper size temporarily, the maximum settable size is 3.2 m. Also, the setting
of Custom Size is disabled when you exit the application software.
Note
Registering and Printing With a Custom Paper Size
This topic describes how to register a non-standard paper size by the name of 430 mm Square and print based on the
following example.
Document: Any Type
•
Page Size: A square sheet (430 × 430 mm [16.9 × 16.9 in])
•
Paper: Sheets
•
Media Type: Any type
•
Paper Size: A square sheet (430 × 430 mm [16.9 × 16.9 in])
•
1
Load the square paper (430 × 430 mm [16.9 × 16.9 in]) in the printer.
2
Choose Print in the application menu.
3
Select the printer in the dialog box, and then display the printer driver dialog box. (See "Accessing the Printer
Driver Dialog Box from Applications .")
4
Make sure the Main sheet is displayed.
5
A
In the Media Type list, select the type of paper that is loaded.
6
After confirming that
106
P.167
➔
D
Easy Settings is selected, select from the
E
Print Target list.
