Preparing to Transfer the Printer
4
Grasp the Belt, insert it between the Belt Stopper, and
affix the Belt Stopper with a hex screw at the position
indicated.
Important
916
• Here, the Belt Stopper is the one that was removed and stored after initial installation. Neglecting to attach the Belt
Stopper may damage the printer.
Do not touch the Linear Scale (a), Carriage Shaft (b), or
•
Fixed Blade (c). This may stain your hands and damage
the printer.
