Canon imagePROGRAF iPF8400S User Manual page 859

iPF8400S
Setting Item
Roll Paper Width
Conserve Paper
Media Type
Print Priority
Print Quality
Highest quality
Extend print pass
Paper Source
Automatic Cutting
Print Labels
7
Configure the color measurement settings and drying
settings, and then click Next.
Setting Item
Color Measurement Preferences
Reduce Drying Time
User's Guide
Click the Acquire Info. button to display the paper width of the roll loaded in the printer.
Selecting this check box allows you to conserve paper by reducing the gap between the pieces
of a color chart when the chart is printed split into pieces.
Select the type of paper.
Choose the graphic elements that you want to emphasize for printing.
For details on the settings, see "Giving Priority to Particular Graphic Elements and Colors for
Printing."
P.59
➔
Choose the print quality.
For details on the settings, see "Giving Priority to Particular Graphic Elements and Colors for
Printing."
P.59
➔
If you select this option, the document will be printed with enhanced quality at the highest reso-
lution. Compared to the other options, more time and ink are consumed in printing, however
you will attain print results with the highest quality.
Uneven printing may occur when printing with the Highest setting in Print Quality. Selecting
this check box may improve the uneven printing. However, the printing speed will be reduced.
Selects the paper source.
Selects how to cut the paper when Acquire Color Measurement Data finishes.
Select this check box to print the color chart printing information.
Configures the pattern size to print the color charts and the drying settings for the printed color
charts.
Choose Standard to print at the standard pattern size and dry using the standard setting val-
ues.
Click the Settings button to display the Color Measurement Preferences dialog box, which
allows you to configure the pattern size and drying method in detail.( *1 )
Selecting this check box reduces the drying time.
Once the time configured in the Color Measurement Env. sheet in the Preferences dialog box
has elapsed, color measurement proceeds without performing any further drying with the venti-
lation fan.
Specify a time that offers sufficient drying by air drying in the Preferences dialog box. If you
perform color measurement while the ink is not dry, the measurements may not be correct.
The Preferences dialog box is displayed when you click Preferences in the imagePROGRAF
Color Calibration Management Console menu.
Acquiring Color Measurement Data For Any Color Chart
Details
Details
