Printing on Non-Standard Paper Sizes (Mac OS)
6
In Paper Size, enter the height and width of the original. Here, enter 43.00 cm in Height and Width.
7
In Non-Printable Area, enter 0.5 for the top and side margins and 2.3 for the bottom margin. Here, measure-
ments are entered in centimeters.
8
Double-click Untitled in the list at left in the Custom Paper Sizes dialog box and enter the paper name—in
this case, 430*430.
9
Click OK to close the Custom Paper Sizes dialog box.
10
F
In the Paper Size list, click the size of the original. In this case, click 430*430, the size you registered.
11
If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then
select Print from the application software menu.
12
Access the Main pane.
13
A
In the Media Type list, select the type of paper that is loaded.
14
After confirming that
15
Make your selection in the
16
Access the Page Setup pane.
110
17
Click Cut Sheet in the
18
C
In Page Size, make sure 430*430 is displayed, as registered in Page Setup.
D
Easy Settings is selected, select from the
F
Print Quality list.
A
Paper Source list.
E
Print Target list.
