Menu Settings
Print Job Log
Pause Print
HDD Information
*1: A rough estimate of the amount of ink consumed per print job is displayed. Actual ink consumption may be different. The average margin
of error for estimates calculated according to Canon measurement conditions for ink costs is ±15%. Canon does not guarantee the
accuracy of these estimates. Estimates may vary depending on conditions of use. Calculation of these estimates does not include ink
consumed when cleaning printheads by forceful ejection of ink.
Set./Adj. Menu
Limited items are displayed during printing. The displayed items are indicated by annotations.
Test Nozzle Check
Print
Status Print
Interface Print
Paper Details
Print Job Log
Menu Map
Adjust Head
Printer Posi.
Adj.
644
Feed Pri-
ority
Setting Item
Setting Item
Standard
Simple
Other Initial adjustmt
Manual
Adj. Pri- Automatic
ority
Print Quality
Description, Instructions
Print a record of print jobs, including the paper type and size, amount
of ink consumed, and so on. Ink consumption indicates a rough esti-
mate of the amount of ink consumed per print job.( *1 )
Choose On to stop printing.
Indicates the total hard disk capacity and the mail box free space.
Description, Instructions
Print a test pattern to check the nozzles.
Print information about the setting values and condition of the
printer.
Print interface settings information.
Print the paper settings as specified in Paper Details.
Print a record of print jobs, including the paper type and size,
amount of ink consumed, and so on. Ink consumption indicates
a rough estimate of the amount of ink consumed per print job.
( *1 )
Print the menu structure.
An adjustment pattern is printed and the print position is auto-
matically adjusted to fix misaligned printing. Select Standard if
vertical lines in printed material are warped or colors are out of
alignment. Select Standard also if the printing results are not
improved by executing Simple. (See "Automatic Adjustment to
Straighten Lines and Colors.")
An adjustment pattern is printed and the print position is auto-
matically adjusted to fix misaligned printing. Simple executes a
simple adjustment in a short time. Select Simple when fre-
quently adjusting the printhead, such as during daily mainte-
nance. (See "Automatic Adjustment to Straighten Lines and Col-
ors.")
P.768
➔
Printhead position adjustment is executed during the initial set-
up. If adjusting the printhead position has not been performed
such as due to an error during initial setup or the state of the
operating settings when replacing the printhead, select Initial
adjustmt. (See "Adjustment When Installing the Print-
head.")
P.771
➔
Input the setting values from the adjustment pattern printing re-
sults and adjust the printing position to fix misaligned printing.
Normally, select Standard. However, when printing on special
paper, or if printing is not improved after Standard, try Manual.
(See "Manual Adjustment to Straighten Lines and Col-
ors.")
P.770
➔
Specify exact paper feeding, if desired. Normally, select Auto-
matic. Choose Print Quality for attractive printing. Choosing
Print Quality also makes banding less noticeable. Choose
Print Length if you prefer to feed the paper an exact amount.
iPF8400S
P.768
➔
