This displays the Color Calibration Management Console main window.
• If there is no Color Calibration Management Console icon on the desktop, click start and navigate to All Programs>im-
agePROGRAF Color Calibration Management Console>imagePROGRAF Color Calibration Management Console.
Note

Main Window

Main Window

The Color Calibration Management Console main window consists of a title bar, menu bar, Printer list, Calibration
sheet, and Color Measurement sheet.
You can switch between the Calibration sheet and Color Measurement sheet by clicking the
B
Color Measurement button. You can also switch between the sheets from the File menu in the menu bar.
• Title bar
Displays the model name, port name, and installation location of the printer selected in the Printer list.
• Menu bar
Allows you to select the menu items for the necessary operations.
For details on each of the menu items, refer to the following topics.
File Menu
• P.807
➔
Tools Menu (When the Calibration Sheet is Displayed)
•
Tools Menu (When the Color Measurement Sheet is Displayed)
•
Help Menu
•
P.811
➔
User's Guide
P.809
➔
P.809
➔
Main Window
A
Calibration button or
