Resizing Originals to Match the Paper Size (Windows)
Paper: Roll
•
Paper type: Plain Paper
•
Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
•
1
Choose Print in the application menu.
2
Select the printer in the dialog box, and then open the printer driver dialog box. (See "Accessing the Printer
Driver Dialog Box from Applications .")
3
Make sure the Main sheet is displayed.
4
A
In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper.
5
Select the printing application in the
6
Click the Page Setup tab to display the Page Setup
sheet.
7
Select and click a roll paper in the
66
8
Select the width of the loaded roll in the
9
A
In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4.
P.167
➔
E
Print Target list.
L
Paper Source list.
M
Roll Paper Width list—in this case, ISO A2/A3 Roll (420.0mm).
