Binding Settings Dialog Box

Specify Folded Size
Rotate Page 90 degrees (Con-
serve Paper)

Binding Settings Dialog Box

Binding Settings Dialog Box
This is displayed when you select Binding Settings from theEdit menu. This allows you to configure the binding
edge settings.
• Binding Edge
Configures the binding edge when folding paper.
The following settings are available for the binding edge.
Bottom
Top
• Binding
Configures the binding margin (gutter).
Prints by creating a binding margin (gutter) of the specified size. Enter the margin size as a number.
•
The values that can be entered are 0 to 50 (mm).
Note
• Print Fold Lines
Configures the color and type of fold lines.
•
To not print fold lines, clear the Print Fold Lines checkbox.
Note
• Fold Line Color
You can select the fold lines.
206
• Fold Line Type
You can select the fold lines.
The following settings are available for the fold line type.
Solid Line
Dotted Line
Dashed Line
Setting
Prints by automatically enlarging or reducing the entire document to match the size of the
paper. Select the actual size of the paper you want to print on in Fit Paper Size.
Prints by rotating pages by 90 degrees. Pages are automatically rotated if they will fit with-
in the roll paper width when rotated, and are not rotated if they will not fit within the roll
paper width.
Setting
Prints by placing the binding margin (gutter) at the bottom of the document.
Prints by placing the binding margin (gutter) at the top of the document.
Setting
You can print the solid line as the frame style.
You can print the dotted line as the frame style.
You can print the dashed line as the frame style.
Details
Details
Details
