Zoom Dialog Box

The following settings are available for orientation.
Vertical
Horizontal
• Roll Paper Length
Set the length of one page to print on roll paper.
When you place a checkmark on Auto Settings, the one-page length to be printed on roll paper is automatically
set so that the laid-out objects are printed on one page.
• Available only if rolls are selected in Paper Source.
• You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
Note
• You can change the numbers by clicking either ▲ button or ▼ button.
• Order
Set the object layout order.
The following settings are available for order.
Upper Left to Right
Upper Left to Bottom
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Vertical, you can choose only
Upper Left to Right.
Note
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Horizontal, you can choose
only Upper Left to Bottom.
• Paper Size
You can select the size of the print media.
• You cannot display this if Roll Paper is selected in Paper Source.
Note

Zoom Dialog Box

Zoom Dialog Box
This dialog box appears when you select Zoom from the View menu. You can enlarge or reduce the screen display.
• Scaling
Set the magnification for enlargement or reduction of the screen display.
• You can input between 10 and 400.
• You can change the numbers by clicking ▼ button.
Note
408
Setting
Prints the image and text created with the application software in the orientation as it is.
Prints the image and text by rotating sideways 90 degrees from the orientation as specified in the
application.
Setting
The objects are laid out from upper left to right.
The objects are laid out from upper left to bottom.
Details
Details
