Chapter 7, Installing Internal Drives
The system must be plugged in (see step 2 on page 103) for this to work.
8.
To replace the side panel, reverse steps 4 through 7; then you can re-
connect everything.
Be careful not to get any of the cables caught in the cover or stuck in the
CAUTION!
fan housing when you put the cover back on the computer.

Installing the drive

1.
Be sure you have set the SCSI ID.
Set the SCSI ID as explained in ÒPrepare the driveÓ on page 100.
2.
If you havenÕt done so, remove the cover from the computer.
See ÒRemoving the cover,Ó starting on page 103 for instructions.
Make sure the computer is powered down before removing the cover.
WARNING!
Touch the metal plate over the power supply to discharge any static
CAUTION!
electricity that might have built up on your clothes or body.
The system must be plugged in (see step 2 on page 103) for this to work.
Use an anti-static grounding strap and handle hard drives by the housing
only; avoid touching any exposed electronics or connectors.
3.
Set the computer upright.
Starting with the top bezel tab, push on the three tabs on the left side
which hold the bezel in place.
Press up on the top tab and down on the other two, and pull the tabbed
side of the bezel away from the case until the tabs on the other side of the
bezel clear the front of the computer, and set the bezel aside.
106
PowerTower Pro UserÕs Guide
