Chapter 6, Adding Memory

Removing a DIMM

1.
If you need to remove a DIMM module to make room for a higher-capacity
one, reach in and push down on the tiny lever at the end of the DIMM slot.
A. push
2.
The DIMM should pop loose from the slot at the lever end.
3.
If the DIMM module does not come free, press the DIMM lever down again.
4.
Grasp the DIMM module with one hand at each end and pull the module
up and out of the slot.
5.
When you are Þnished with DIMM removal and insertion, put the cover
back on the computer, and re-connect the external cables.
Be careful not to get any of the cables caught in the cover or stuck in the
CAUTION!
fan housing when you put the cover back on the computer.
Inserting a DIMM
Touch the metal plate over the power supply to discharge any static
CAUTION!
electricity that might have built up on your clothes or body.
80
PowerTower Pro UserÕs Guide
lever
lever
down
B. lift DIMM out
