Chapter 6, Adding Memory
3.
Place the expansion slot cover over the PCI expansion slot, but do not
reinsert the screw.
4.
Read this step before proceeding.
This step is intended to provide an overview of the crossbar assembly installation
procedure. Use the following illustration for reference only. Detailed installation
instructions follow.
In general, the crossbar assembly must be secured to the chassis by two hooks on the
front end of the beam, which Þts into two slots on the 5.25 inch drive bay rack.
A screw attaches the rear of the beam to the rear chassis panel, and a second screw
attaches the RAID rack cage to the PCI expansion slot closest to the CPU card. The
RAID rack rests on two legs on top of the CPU card.
86
PowerTower Pro UserÕs Guide
For Technical Support, Call 1-800-708-6227
