The four-pin audio connector should be connected so that the lip on the connector faces
away from the drive bay edge of the motherboard. You may have to temporarily remove
the some of the other cables from their connectors to be able to reach in and seat the
CD-ROM connector.
Make sure all four pins are enclosed in the connector.
Make sure the connectors are replaced and snug.
Check the instructions that came with the drive for jumper or switch settings and check
to make sure that they are properly set before going to the next step.
10.
Replace and re-connect any drives removed to obtain access to the drive
bay.
11.
If you are Þnished, proceed to ÒPutting the computer back togetherÓ on
page 137.
For Technical Support, Call 1-800-708-6227
CD SND INPUT
connector
fan connector
Chapter 7, Installing Internal Drives
main power
supply
connector
