The DIMM slots are organized into two banks, A and B. Bank A is toward the bottom and
Bank B is above it, as labeled on the motherboard. Each bank has four slots, numbered A1Ð
A4 and B1Ð B4.
DIMMs can be inserted in any order, but to achieve best performance, insert DIMMs of the
same capacity in corresponding slots (A1 with B1, A2 with B2, etc.), to interleave RAM
memory.
All DIMMs must be 168-pin, fast-paged mode, 70-nanosecond RAM access time or faster.
You can install 8 MB, 16 MB, 32 MB, 64 MB, or 128 MB DIMMs up to a total capacity of
1 GB (i.e. 1024 MB).
To increase your systemÕs RAM, install additional DIMM modules in vacant DIMM slots;
if there are no vacant slots, remove one or more lower-capacity DIMMs (see ÒRemoving a
DIMMÓ on page 80) and replace them with modules of higher capacity. (see ÒInserting a
DIMMÓ on page 80.)

Installing and removing RAM

1. If you are not proÞcient with electronic equipment, Power Computing
CAUTION!
Corporation recommends that you have a certiÞed technician install
RAM, drives, and PCI expansion cards. If you attempt to install RAM,
drives, or cards yourself, any damage you may cause to your equipment
will not be covered by the limited warranty on your computer. Please call
technical support at 1-800-708-6227 for additional information about this
or any other warranty question.
2. If an anti-static bracelet is available, put it on and ground it to the
computer chassis before touching any components inside the computer.
3. Handle DIMMs by the ends and avoid touching their contacts or other
metal components.
4. Always store DIMMs in anti-static bags.
5. Take your time; donÕt hurry.
For Technical Support, Call 1-800-708-6227
Chapter 6, Adding Memory
PowerTower Pro UserÕs Guide
73
