Chapter 6, Adding Memory
3.
Remove the crossbar assembly.
The crossbar assembly consists of a crossbar, a RAID rack, and a fan; the entire
assembly must be removed to install RAM.
Place the computer on its side with its open side up.
Remove the screw that secures the crossbar to the rear panel.
Remove the screw that secures the crossbar to the PCI expansion slot cover.
rear-panel
screw
PCI expansion
slot cover
screw
RAID rack
76
PowerTower Pro UserÕs Guide
crossbar
assembly
For Technical Support, Call 1-800-708-6227
