Chapter 7, Installing Internal Drives
7.
Connect one of the unused connectors on the SCSI cable to the wide
connector on the drive (see illustrations following).
Find the internal SCSI cable inside the computer (it is the wide ßat ribbon cable
connected to the motherboard connector to the immediate left of the power cable).
external SCSI cable
is connected to the
motherboard here
The internal SCSI cable should have one or more unused connectors on it. You may
have to detach and re-attach the SCSI connectors on one or more other drives to get
connectors where you need them. Remember, this is SCSI, so the ends have to be
terminated. See ÒEnsuring proper terminationÓ on page 17 for details.
116
PowerTower Pro UserÕs Guide
power
connector
internal SCSI cable
is connected to the
motherboard here
