Chapter 5, Installing PCI Expansion Cards
4.
Remove the card to be installed from its static-proof bag.
Hold the card by its non-metallic edges and its metal slot cover to avoid touching
components or connector contacts on the card.
5.
Align the card over the card slot.
Make sure that
Ð the PCI connector on the bottom of the card lines up with the PCI socket on the riser
card.
Ð the slot cover on the PCI card lines up with the slot in the back panel.
Ð the slot cover tongue Þts into the groove at the base of the slot.
slot
slot
cover
screw
PCI card slot cover
64
PowerTower Pro UserÕs Guide
groove
slot cover
tongue
For Technical Support, Call 1-800-708-6227
PCI card connector
PCI socket
