Chapter 7, Installing Internal Drives
4.
Remove the crossbar assembly.
The crossbar assembly consists of a crossbar, a RAID rack, and a fan; you must remove
the crossbar assembly to install internal drives.
Place the computer on its side with the open side up.
Remove the screw that secures the crossbar to the rear panel.
Remove the screw that secures the crossbar to the PCI expansion slot cover.
rear-panel
screw
PCI expansion
slot cover
screw
RAID rack
108
PowerTower Pro UserÕs Guide
crossbar
assembly
For Technical Support, Call 1-800-708-6227
