Output Mode

Definition: Sets the condition in which the discrete output is de-activated.
Serial Cmd: <K810,output on,active state,pulse
sis mode,trigger evaluation period,number to output on,decodes per
trigger>
Default:
Pulse
Options: 0 = Pulse
1 = Latch Mode 1
Pulse
Definition: This is the default mode of operation in which the programmable output
is activated when the Output On condition has been met and held active
for the duration of the selected pulse width.
Latch Mode 1 (Unlatch on Discrete Input 1)
Definition: The programmable output is active when the Output On condition has
been met and held active until the discrete Input 1 has been activated.
Latch Mode 2 (Unlatch Opposite Condition)
Definition: The programmable output is activated when the Output On condition
has been met and held active until the opposite condition selected under
Output On has been met.
For example, if Noread is enabled under Output On, the programmable
output will go active upon a noread and remain active until the opposite
condition, a good read, occurs.
Latch Mode 3 (Unlatch Re-enter Read Cycle)
Definition: The programmable output is active when the Output On condition has
been met and is held active until a new read cycle begins.
NOTE: All of the Output On modes are inhibited when any Output on Warning is
active for Output 1 (see <K713> command).
Chapter 8 I/0 Parameters
width,output mode,trend analy-
2 = Latch Mode 2
3 = Latch Mode 3
MS-9 Scanner User's Manual
8-13
