Scanning Parameters
Scanning mirror type: Rotating, single line 9-faceted
Scan Rate:2000 scans per second
Scan width angle: Typically 56°; Pitch: ±°
Communication
RS-232, RS-422/485, Daisy chaincan be used with an accessory IB-131 Interface
Symbologies
Standard offering: Code 128, Code 39, Code 93, Codabar, Interleaved 2 of 5, UPC/EAN
Special offering: OMR, Pharmacode
FIS Options
FIS # Density
001 Low Density
002 High Density
003 Low Density
004 High Density
005 Low Density
006 High Density
007 Low Density
1001 Low Density
1002 Low Density
1003 Low Density
Mounting Specifications
Line
Single Line
Single Line
Single Line Standard + OMR
Single Line Standard + OMR
Raster
Raster
Single Line Standard + Pharmacode
Single Line
Raster
Single Line
Drill three
diameter holes.
Caution: Maximum penetration
depth of screws is
cm).
Caution: To prevent twisting or dis-
tortion of the scanner housing,
ensure that the mounting surface is
flat.
Software
Standard
Standard
Standard
Standard
Standard Invisible
Standard Invisible
OMR Invisible
inch
0.203
0.30

Figure A-2 MS-9 Mounting

MS-9 Scanner User's Manual
Appendices
Ink
Visible
Visible
Visible
Visible
Visible
Visible
Visible
(5.16 mm)
inch (0.762
A-3
