Output 1 Parameters
Active State
Definition:
Sets the active state of the discrete output.
Serial Cmd:
<K810,output on,active state,pulse width,output mode,trend analysis
mode,trigger evaluation period,number to output on,decodes per trig-
ger>
Default:
Normally Open
Options:
0 = Normally Open
Pulse Width
Definition:
Sets the time in 10 mS increments that the discrete output remains active.
Serial Cmd:
<K810,output on,active
mode,trigger evaluation period,number to output on,decodes per trig-
ger>
Default:
(.05 seconds). Corresponds to 50 mS displayed in the menu.
5
Options:
1 to 255 (0.01 to 2.55 seconds). Divide the number entered on the com-
mand line by 100 for time in seconds.
8-12
MS-9 Scanner User's Manual
1 = Normally Closed
state,pulse
width,output mode,trend analysis
