Appendix B — Electrical Specifications
Narrow-
bar-
Visible Ink
width
.005"
(.127 mm)
.0075" 2" to 5"
(.190 mm) (51 to 127 mm)
.010" 1.5" to 6"
(.254 mm) (38 to 152 mm)
.015" 1" to 7"
(.381 mm) (25 to 178 mm)
.020" 1" to 9"
(.508 mm) (25 to 229 mm)
Maximum Operating Power: 6.5 Watts
:
Cabling Power Input: 10 to 28 VDC, 200 mV p-p max. ripple, 185 mA @ 24 VDC (typical)
Trigger, New Master: 4.5 to 28 VDC (optoisolated)
OMR & New Master Trigger Input: Optoisolated, 10 to 28 VDC Outputs (1,2,3): 1 to 28 VDC
(optoisolated) rated
(I <100 mA @24 VDC, current limited by user)
CE
3-foot cable terminated with a 15-pin high density D-Sub connector plug.
Host
Pin
RS232
1 Power +10 to 28 VDC
2 TxD
3 RxD
4 Power/Signal ground
5
6 RTS
7
Low Density
Invisible
Ink
1.5" to 4"
(38 to 101mm)
1.5" to 6"
(38 to 152 mm)
1.5" to 6"
(38 to 152 mm)

Table A-2 MS-9 Host Connector, 15-pin

Host & Aux
RS232 RS422/485
TxD TxD (–)
RxD RxD (–)
Trigger (–)
Aux TxD TxD (+)
Output 1 (+)
High
Density
1.75" to 3"
(44 to 76 mm)
1.5" to 4"
(38 to 101 mm)
Host In/
Out
In
Out
In
In
Out
Out

Figure A-4 MS-9 Connector

MS-9 Scanner User's Manual
Appendices

Figure A-3 MS-9

Read Range Graph

A-5
