RS-232/422 Host Port

Includes host port connections and host protocols.
Host Port Connections
Baud Rate, Host Port
Usage: Can be used to transfer data faster or to match host port settings.
Definition: The rate at which the scanner and host transfer data back and forth.
Serial Cmd: <K101,aux port
ID status,daisy chain ID>
Default:
9600
Options: 1 = 1200
2 = 2400
3 = 4800
Parity, Host Port
Usage: Only changed if necessary to match host setting.
Definition: An error detection routine in which one data bit in each character is set to
1 or 0 so that the total number of 1 bits in the data field is even or odd.
Serial Cmd: <K100,baud rate,parity,stop bits,data bits>
Default:
Even
Options: 0 = None
Stop Bits, Host Port
Usage: Only changed if necessary to match host setting.
Definition: One or two bits added to the end of each character to indicate the end of
the character.
Serial Cmd: <K100,baud
Default:
One
Options: 0 = One
mode,baud rate,parity,stop bits,data bits,daisy chain
4 = 9600
5 = 19.2 K
6 = 38.4 K
1 = Even
rate,parity,stop bits,data bits>
1 = Two
Chapter 3 Communications
7 = 57.6 K
8 = 115.2 K
2 = Odd
MS-9 Scanner User's Manual
3-3
