CDM-710G High-Speed Satellite Modem
Installation
Support Bracket
#10 Bracket Bolt
Figure 2-1. Installation of Optional Rear-Mounting Support Brackets (KT/6228-2)
#10 Shoulder Screw
#10 Flat Washer
#10 Flat Washer
#10 Split Washer
#10 Hex Nut
Equipment Rack
Rear Mounting Rail
Back of unit
2–3
Revision 1
MN-CDM710G
