Condition 3 - Power On of Faulted BBU (Powered on and then fault detected.)
PCB# 348-0040099
Full Charge LED - Will follow conditions 1 or 2, then OFF when fault
detected.
PCB# 348-0038395
Full Charge LED - Will follow conditions 1 or 2, then OFF when fault
detected.
PCB# 348-0041453
Full Charge LED - Will follow conditions 1 or 2, then OFF when fault
detected.
All PCBs
Fault LED - OFF until fault detected, then ON solid
Condition 4 - BBU does not reach fully charged state within required time limit, a fault error
is generated.
PCB# 348-0040099
Full Charge LED - OFF while charging, remains OFF after fault error is
generated.
PCB# 348-0038395
Full Charge LED - BLINKING while charging, changes to OFF when fault
error is generated.
PCB# 348-0041453
Full Charge LED - BLINKING while charging, changes to OFF when fault
error is generated.
All PCBs
Fault LED - OFF until fault error is generated, then solid ON
