Moving this to a slot previously
type of disk.... occupied by this type of
disk....
LUN None or Unassigned
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the
array)
Global hot spare None or Unassigned
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the
array
Unassigned or None or Unassigned
new
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the
array)
results in this behavior.
Disk remains part of its original LUN. If disk was
moved from another array, the receiving array
will try to create a new LUN to accommodate
the disk.
Disk becomes a global hot spare. All data on
the disk is lost.
Disk replaces failed disk and becomes part of
new LUN. All original LUN data on the disk is
lost.
Disk remains part of its original LUN. If the disk
was moved from another array, the receiving
array will try to create a new LUN to
accommodate the disk.
Disk remains global hot spare.
Disk remains global hot spare.
Disk replaces failed disk and becomes part of
LUN.
Disk remains global hot spare.
Disk remains unassigned.
Disk becomes a global hot spare.
Disk replaces failed disk and becomes part of
LUN.
Disk remains unassigned.
