HP Surestore Disk Array 12h - And FC60 Service Manual page 536

Code
0x6C
0x01
0x6C
0x02
0x6C
0x03
0x6C
0x04
0x6C
0x05
0x6E
0xEE
0x80
0x80
0x00
0x81
0x82
0x83
0x84
0x89
0x8A
0x8B
0x8C
536
Description
Drive SCSI Channel 1
Turnaround diagnostics running
Drive SCSI Channel 2
Turnaround diagnostics running
Drive SCSI Channel 3
Turnaround diagnostics running
Drive SCSI Channel 4
Turnaround diagnostics running
Drive SCSI Channel 5
Turnaround diagnostics running
Passive controller - Normal during Firmware download. The controller may be in this
state after power ON (in this case, use the AM60 software to set to "Active" state).
In-between programming steps
Active controller - Normal State
Erasing boot flash segments
Writing boot flash segments
Verifying erase of boot segments
Verifying write of boot segments
Erasing file flash segments
Writing file flash segments
Verifying erase of file flash
segments
Verifying write of file flash
segments
Comments Cause / Solution
HW Diag. status Controller module /
reseat or replace
Firmware file is bad /
Download Firmware
with a good file.
Firmware file is
downloading or
Firmware file is bad /
Download Firmware
with a good file.
