Moving this to a slot previously occupied
type of disk.... by this type of disk....
LUN None or Unassigned
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the array)
Global hot spare None or Unassigned
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the array)
Unassigned or None or Unassigned
new
Global Hot Spare
Failed LUN Disk
Optimal LUN Disk (original disk
moved to another slot in the array)
274
results in this behavior.
Disk remains part of its original LUN. If disk was
moved from another array, the receiving array will try
to create a new LUN to accommodate the disk.
If the disk is resident, it remains part of its original
LUN.
If the disk is foreign (from another array), the disk
becomes a global hot spare.
Disk replaces failed disk and becomes part of new
LUN. All original LUN data on disk is lost.
Disk remains part of its original LUN. If the disk was
moved from another array, the receiving array will try
to create a new LUN to accommodate the disk.
Disk remains global hot spare
Disk remains global hot spare
Disk replaces failed disk and becomes part of LUN
Disk remains global hot spare
Disk remains unassigned
Disk becomes a global hot spare.
Disk replaces failed disk and becomes part of LUN
Disk remains unassigned
