Managing the HP SureStore E Disk Array 12H on MPE
Configuring AutoRAID SCSI LUNs for MPE/iX

LDEV (SCSI LUN) Configuration

The next and last item to configure is the LDEV number. If this is the first time the user is performing this
to an AutoRAID, then LUN 0 should be configured. As mention in the first note in this chapter, the user is
required to have LUN 0 be the lowest LDEV number.
NOTE! The SYSGEN product ID for ALL AutoRAID devices is HPDARRAY.
To configure the LDEV number to the AutoRAID as follows:
io> ad 30 id=hpdarray path=10/16/4.1.0
io> ld 30
LDEV: 30 DEVNAME
ID: HPDARRAY
PATH: 10/16/4.1.0
CLASS: DISC SPOOL
Once LUN 0 has been configured, adding more LDEVs is done by using only the add device command
(ad). The following is an example of adding LDEV 31 and LDEV 32:
io> ad 31 id=hpdarray path=10/16/4.1.1
io> ad 32 id=hpdarray path=10/16/4.1.2
For more information on the SYSGEN configuration, refer to the MPE/iX System Startup, Configuration,
and Shutdown Reference Manual, part number (36650-90042).
124
OUTDEV: 0 MODE:
RSIZE: 128 DEVTYPE: DEVC
MPETYPE 4 MPESUBTYPE: 2
