Brocade Communications Systems StoreFabric SN6500B Administrator's Manual page 86

4
Performing a firmware download
4. Enter the host name or IP address, user name, password, and fully-qualified path to the file
5. Select the protocol type in the Protocol Type field.
6. Click Apply.
7.
58
The download source can be located on the Network or a USB device.
NOTE
When you select the USB button, you can specify only a firmware path or directory name. No
other fields on the tab are available. The USB button is available if the USB is present on the
switch.
release.plist.
You can enter the IP address in either IPv4 or IPv6 format.
The path name should use the following structure:
//<directory>/<fos_version_directory>/release.plist
where the <directory> is the path up to the entry point of <fos_version_directory> and
<fos_version_directory> is where the unzipped version of Fabric OS is located.
Example
//directory_1/my_directory/v7.0.0/release.plist
If you select "Secure Copy Protocol (SCP)," you cannot specify "anonymous" in the User field.
The firmware download begins. You can monitor the progress by looking at the Firmware
Download progress bar.
NOTE
About halfway through the download process, after the firmware key is downloaded to the
switch, connection to the switch is lost and Web Tools invalidates the current session. Web
Tools invalidates all windows because upfront login is always enabled and cannot be disabled.
Close all Web Tools windows and log in again.
If the firmware download is in progress when you log in, you can continue to monitor its
progress.
Web Tools Administrator's Guide
53-1002756-01
