Switch Events and Switch Information

Switch Events and Switch Information display as tab forms under Switch View. The information in
the Switch Information tab is polled every 60 seconds.
NOTE
You can click the column head to sort the events by a particular column, and drag the column divider
to resize a column. You can also right-click a column heading to resize one or all columns, sort the
information in ascending or descending order, or select which columns are displayed.
The Switch Information tab displays information about the following items:
•
•
•
•
•
Web Tools Administrator's Guide
53-1002756-01
Switch
-
Name
-
Status
-
Fabric OS Version
-
Domain ID
-
WWN
-
Type
-
Role
The following information is specific to Virtual Fabrics:
-
Base Switch
-
Default Switch
-
Allow XISL Use
Ethernet
-
Ethernet IPv4
-
Ethernet IPv4 netmask Ethernet IPv4 subnet mask address of the switch.
-
Ethernet IPv4 gateway Ethernet IPv4 gateway address of the switch.
-
Ethernet IPv6
FC
-
IPFC IPv4
-
IPFC IPv4 net mask
Zone
-
Effective Configuration Indicates whether zone configuration is enabled or not.
Other
-
Manufacturer serial number
-
Supplier serial number
-
License ID
Name of the switch.
Status of the switch.
Fabric OS version of the switch.
Domain ID of the switch.
World Wide Name of the switch.
Type of the switch.
Role of the switch.
Indicates whether or not the logical switch can act as a base
switch.
Indicates whether or not the logical switch is the default
logical switch.
Indicates whether or not the logical switch is allowed to
connect to other logical switches using an extended
inter-switch link (XISL).
Ethernet IPv4 address of the switch.
Ethernet IPv6 address of the switch.
Fiber Channel IPv4 address.
Fiber Channel IPv4 subnet mask address.
Displays the serial number of the manufacturer.
Displays the serial number of the supplier.
Displays the license ID.
