Advanced performance monitoring graphs

This section describes how to create the advanced performance monitor graphs listed in
on page 91. Because the procedure for creating these graphs differs depending on the type of
graph, each type is described separately in the sections that follow.
The advanced monitoring graphs are not supported for GbE ports.
NOTE
You must have an Advanced Performance Monitoring license installed to use the Advance
Performance Monitor features. If user-defined Admin Domains are configured, Advanced
Performance Monitoring works only in AD255.

Creating SID-DID Performance graphs

The SID/DID Performance graph displays the traffic between a SID-DID pair on the switch being
managed.
To create a SID-DID performance graph, perform the following steps.
1. Open the Performance Monitoring window.
2. Select Performance Graphs > Advanced Monitoring > SID/DID Performance. The SID/DID
3. Click a port from the Slot/Port or Sid/Did Selection List.
4. Select a source ID from the Port or Sid/Did Selection List, and click Add Sid.
5. Select a destination ID from the Port or Sid/Did Selection List, and click Add Did.
6. Click OK.
Web Tools Administrator's Guide
53-1002756-01
Performance Setup dialog box displays.
•
To see the end-to-end (EE) monitors that are currently set up on a particular port, proceed
to step 3.
•
To specify the port, Source ID and Domain ID, skip to
NOTE
Only the FC ports of the launched switch display in the tree. The All Devices tab lists all the
devices in the fabric and lets you select the source and destination. Slot and port information
of other switches is not displayed in the tree.
a. Drag the selected port into the Enter/drag slot, port number field.
b. Click Retrieve preset EE monitors. The current end-to-end monitors for that port are
displayed in the "Current EE monitors set for selected port" table.
c. Optional: To display a performance graph for the current EE monitors set for the selected
port, click a SID-DID pair in the table. You can select multiple Source ID and Destination
IDs. Click Select. If you selected multiple SID/DID monitors, click OK in the confirmation
dialog box that displays. Skip to
for the current EE monitors set for the selected port, continue with
You can also enter a source ID in the Enter/drag SID number field.
You can also enter a destination ID in the Enter/drag DID number field.

Advanced performance monitoring graphs

step
step 6. If you do not want to display a performance graph
Table 12
4.
step 4.
