8

Zoning configurations

LSAN zone requirements

An LSAN zone enables device connectivity between fabrics connected in Fibre Channel Routing
(FCR) configurations without forcing you to merge fabrics. Extension switches provide multiple
mechanisms to manage interfabric device connectivity. Zones that contain hosts and targets that
are shared between the two fabrics need to be explicitly coordinated. To share devices between any
two fabrics, you must create an LSAN zone in both fabrics considering the following:
•
•

QoS zone requirements

A QoS zone is a special zone that assigns a Quality of Service (QoS) level for traffic flow between a
given host or target pair. The members of a QoS zone are WWNs of the host or target pairs. QoS
zones can contain only WWN members. A QoS zone has a special prefix, to differentiate it from a
regular zone. The formats and meaning of the QoS zone name prefix are shown in
names are not case dependent).
TABLE 14
QoS name prefix
QosH_
QosM_
QosL_
Zoning configurations
The Zone Administration window is where all of the zoning tasks are performed.
When performing zoning tasks for switches in a mixed fabric—that is, a fabric containing two or
more switches running different fabric operating systems—you should use the switch with the
highest Fabric OS level. Refer to
recommendations about zoning.

Opening the Zone Admin window

Launching the Zone Administration window and performing any kind of zone configuration takes
more time if there are a large number of entries in the zone database. If the zone count is above
10000, the time taken for completing the operation increases proportionately.
You cannot open the Zone Administration window from AD255 (physical fabric).
To open a Zone Adminstration window, perform the following steps.
1. Select a switch from the Fabric Tree.
2. Click Configure > Zone Admin.
104
The name of an LSAN begins with the prefix LSAN_. The prefix is not case sensitive.
Members must be identified by their port WWN because port IDs are not necessarily unique
across fabrics.
QoS zone name prefixes
Priority
High
Medium
Low
The Zone Administration window displays, as shown in
Bandwidth assignment
Five virtual circuits, 60% of available bandwidth
Four virtual circuits, 40% of available bandwidth
Two virtual circuits, 10% of available bandwidth
"Best practices for zoning"
Table 14
on page 122 for more
Figure 24.
Web Tools Administrator's Guide
(the
53-1002756-01
