Setting up the MikroTik IP Telephone
If you pick up the handset, a dialtone should be heard.
The basic telephony configuration should be as follows:
• Add a voip voice port to the /ip telephony voice-port voip for each of the devices you want to
call, or want to receive calls from, i.e., (the IP telephony gateway 10.1.1.12 and the Welltech
IP telephone 10.5.8.2):
[admin@Joe] ip telephony voice-port voip> add name=gw remote-address=10.1.1.12
[admin@Joe] ip telephony voice-port voip> add name=rob remote-address=10.5.8.2
[admin@Joe] ip telephony voice-port voip> print Flags: X - disabled, D - dynamic, R
- registered # NAME AUTODIAL REMOTE-ADDRESS JITTER-BUFFER PREFERED-CODEC SIL FAS 0
gw 10.1.1.12 100ms none no yes 1 rob 10.5.8.2 100ms none no yes [admin@Joe] ip
telephony voice-port voip>
You should have three vioce ports now:
[admin@Joe] ip telephony voice-port> print Flags: X - disabled # NAME TYPE AUTODIAL
0 linejack1 linejack 1 gw voip 2 rob voip [admin@Joe] ip telephony voice-port>
• Add at least one unique number to the /ip telephony numbers for each voice port. This
number will be used to call that port:
[admin@Joe] ip telephony numbers> add dst-pattern=31 voice-port=rob [admin@Joe] ip
telephony numbers> add dst-pattern=33 voice-port=linejack1 [admin@Joe] ip telephony
numbers> add dst-pattern=1. voice-port=gw prefix=1 [admin@Joe] ip telephony numbers>
print Flags: I - invalid, X - disabled, D - dynamic, R - registered # DST-PATTERN
VOICE-PORT PREFIX 0 31 rob 31 1 33 linejack1 2 1. gw 1 [admin@Joe] ip telephony
numbers>
Here, the dst-pattern=31 is to call the Welltech IP Telephone, if the number 31 is dialed on
the dialpad. The dst-pattern=33 is to ring the local telephone, if a call for number 33 is
received over the network. Anything starting with digit '1' would be sent over to the IP
Telephony gateway.
Making calls from the IP telephone 10.0.0.224:
• To call the IP telephone 10.5.8.2, it is enough to lift the handset and dial the number 31
• To call the PBX extension 13, it is enough to lift the handset and dial the number 13
After establishing the connection with 13, the voice port monitor shows:
[admin@Joe] ip telephony voice-port linejack> monitor linejack status: connection
port: phone direction: port-to-ip line-status: unplugged phone-number: 13
remote-party-name: PBX_Line [10.1.1.12] codec: G.723.1-6.3k/hw duration: 16s
[admin@Joe] ip telephony voice-port linejack>
Setting up the IP Telephony Gateway
The IP telephony gateway [voip_gw] requires the following configuration:
• Set the regional setting to match our PBX. The mikrotik region will be used in thisn example:
[admin@voip_gw] ip telephony voice-port linejack> set linejack1 region=mikrotik
[admin@voip_gw] ip telephony voice-port linejack> print
Flags: X - disabled
0 name="linejack1" autodial="" region=mikrotik playback-volume=0
