Specifications
Packages required: system
License required: level1
Home menu level: /interface bonding
Standards and Technologies: None
Hardware usage: Not significant

Related Documents

• Linux Ethernet Bonding Driver mini-howto
Description
To provide a proper failover, you should specify link-monitoring parameter. It can be:
• MII (Media Independent Interface) type1 or type2 - Media Independent Interface is an abstract
layer between the operating system and the NIC which detects whether the link is running (it
performs also other functions, but in our case this is the most important).
• ARP - Address Resolution Protocol periodically (for arp-interval time) checks the link status.
link-monitoring is used to check whether the link is up or not.
Property Description
arp ( disabled | enabled | proxy-arp | reply-only ; default: enabled ) - Address Resolution Protocol
for the interface
• disabled - the interface will not use ARP
• enabled - the interface will use ARP
• proxy-arp - the interface will use the ARP proxy feature
• reply-only - the interface will only reply to the requests originated to its own IP addresses.
Neighbour MAC addresses will be resolved using /ip arp statically set table only
arp-interval ( time ; default: 00:00:00.100 ) - time in milliseconds which defines how often to
monitor ARP requests
arp-ip-targets ( IP address ; default: "" ) - IP target address which will be monitored if
link-monitoring is set to arp. You can specify multiple IP addresses, separated by comma
down-delay ( time ; default: 00:00:00 ) - if a link failure has been detected, bonding interface is
disabled for down-delay time. Value should be a multiple of mii-interval
lacp-rate ( 1sec | 30secs ; default: 30secs ) - Link Aggregation Control Protocol rate specifies how
often to exchange with LACPDUs between bonding peer. Used to determine whether link is up or
other changes have occured in the network. LACP tries to adapt to these changes providing failover.
link-monitoring ( arp | mii-type1 | mii-type2 | none ; default: none ) - method to use for monitoring
the link (whether it is up or down)
• arp - uses Address Resolution Protocol to determine whether the remote interface is reachable
• mii-type1 - uses Media Independent Interface type1 to determine link status. Link status
