Client Configuration - MikroTik RouterOS v2.9 Reference Manual

[admin@MikroTik] tool> bandwidth-server session print
# CLIENT
0 35.35.35.1
1 25.25.25.1
2 36.36.36.1
[admin@MikroTik] tool>
To enable bandwidth-test server without client authentication:
[admin@MikroTik] tool bandwidth-server> set enabled=yes authenticate=no
[admin@MikroTik] tool bandwidth-server> print
authenticate: no
allocate-udp-ports-from: 2000
max-sessions: 10
[admin@MikroTik] tool>

Client Configuration

Command name: /tool bandwidth-test
Property Description
address ( IP address ) - IP address of destination host
assume-lost-time ( time ; default: 0s ) - assume that connection is lost if Bandwidth Server is not
responding for that time
direction ( receive/ transmit/ both ; default: receive ) - the direction of the test
do ( name | string ; default: "" ) - script source
duration ( time ; default: 0s ) - duration of the test
• 0s - test duration is not limited
interval ( time : 20ms ..5s ; default: 1s ) - delay between reports (in seconds)
local-tx-speed ( integer ; default: 0 ) - transfer test maximum speed (bits per second)
• 0 - no speed limitations
local-tx-size ( integer : 40 ..64000 ) - local transmit packet size in bytes
password ( text ; default: "" ) - password for the remote user
protocol ( udp | tcp ; default: udp ) - protocol to use
random-data ( yes | no ; default: no ) - if random-data is set to yes, the payload of the bandwidth
test packets will have incompressible random data so that links that use data compression will not
distort the results (this is CPU intensive and random-data should be set to no for low speed CPUs)
remote-tx-speed ( integer ; default: 0 ) - receive test maximum speed (bits per second)
• 0 - no speed limitations
remote-tx-size ( integer : 40 ..64000 ) - remote transmit packet size in bytes
user ( name ; default: "" ) - remote user
Example
To run 15-second long bandwidth-test to the 10.0.0.211 host sending and receiving 1000-byte UDP
packets and using username admin to connect
Page 604 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
PROTOCOL DIRECTION USER
udp send
udp send
udp send
enabled: yes
admin
admin
admin
