FrameRelay (PVC, Private Virtual Circuit) Interface

Document revision 1.1 (Fri Mar 05 08:14:41 GMT 2004)
This document applies to MikroTik RouterOS V2.9
Table of Contents
Table of Contents

General Information

Summary
Specifications
Description
Additional Documents
Configuring Frame Relay Interface
Description
Property Description
Notes
Frame Relay Configuration
Example with Cyclades Interface
Example with MOXA Interface
Example with MikroTik Router to MikroTik Router
Troubleshooting
Description
General Information
Summary
Frame Relay is a multiplexed interface to packet switched network and is a simplified form of
Packet Switching similar in principle to X.25 in which synchronous frames of data are routed to
different destinations depending on header information. Frame Relay uses the synchronous HDLC
frame format.
Specifications
Packages required: synchronous
License required: level4
Home menu level: /interface pvc
Standards and Technologies:
Hardware usage: Not significant
Description
To use Frame Relay interface you must have already working synchronous interface. You can read
how to set up synchronous boards supported by MikroTik RouterOS:
• Cyclades PC300 PCI Adapters
• Moxa C101 Synchronous interface
Page 196 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
Frame Relay (RFC1490)
