Troubleshooting - MikroTik RouterOS v2.9 Reference Manual

[admin@RemoteOffice] interface pptp-server server> print
enabled: yes
mtu: 1460
mru: 1460
authentication: mschap2
default-profile: default
[admin@RemoteOffice] interface pptp-server server>
Finally, the proxy APR must be enabled on the 'Office' interface:
[admin@RemoteOffice] interface ethernet> set Office arp=proxy-arp
[admin@RemoteOffice] interface ethernet> print
Flags: X - disabled, R - running
# NAME
0 R ToInternet
1 R Office
[admin@RemoteOffice] interface ethernet>
PPTP Setup for Windows
Microsoft provides PPTP client support for Windows NT, 2000, ME, 98SE, and 98. Windows
98SE, 2000, and ME include support in the Windows setup or automatically install PPTP. For 95,
NT, and 98, installation requires a download from Microsoft. Many ISPs have made help pages to
assist clients with Windows PPTP installation.
• http://www.real-time.com/Customer_Support/PPTP_Config/pptp_config.html
• http://www.microsoft.com/windows95/downloads/contents/WUAdminTools/S_WUNetworkingTools/W95Wi
Sample instructions for PPTP (VPN) installation and client setup -
Windows 98SE
If the VPN (PPTP) support is installed, select 'Dial-up Networking' and 'Create a new connection'.
The option to create a 'VPN' should be selected. If there is no 'VPN' options, then follow the
installation instructions below. When asked for the 'Host name or IP address of the VPN server',
type the IP address of the router. Double-click on the 'new' icon and type the correct user name and
password (must also be in the user database on the router or RADIUS server used for
authentication).
The setup of the connections takes nine seconds after selection the 'connect' button. It is suggested
that the connection properties be edited so that 'NetBEUI', 'IPX/SPX compatible', and 'Log on to
network' are unselected. The setup time for the connection will then be two seconds after the
'connect' button is selected.
To install the 'Virtual Private Networking' support for Windows 98SE, go to the 'Setting' menu from
the main 'Start' menu. Select 'Control Panel', select 'Add/Remove Program', select the 'Windows
setup' tab, select the 'Communications' software for installation and 'Details'. Go to the bottom of
the list of software and select 'Virtual Private Networking' to be installed.

Troubleshooting

Description
• I use firewall and I cannot establish PPTP connection
Page 354 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
MTU MAC-ADDRESS
1500 00:30:4F:0B:7B:C1 enabled
1500 00:30:4F:06:62:12 proxy-arp
ARP
