General Information

FTP service through SOCKS server
Let us consider that we have a network 192.168.0.0/24 which is masqueraded, using a router with a
public IP 10.1.0.104/24 and a private IP 192.168.0.1/24. Somewhere in the network is an FTP
server with IP address 10.5.8.8. We want to allow access to this FTP server for a client in our local
network with IP address 192.168.0.2/24.
We have already masqueraded our local network:
[admin@MikroTik] ip firewall nat> print
Flags: X - disabled, I - invalid, D - dynamic
0 chain=srcnat src-address=192.168.0.0/24 action=masquerade
[admin@MikroTik] ip firewall nat>
And the access to public FTP servers is denied in firewall:
[admin@MikroTik] ip firewall filter> print
Flags: X - disabled, I - invalid, D - dynamic
0 chain=forward src-address=192.168.0.0/24 dst-address=:21 action=drop
[admin@MikroTik] ip firewall filter>
We need to enable the SOCKS server:
[admin@MikroTik] ip socks> set enabled=yes
[admin@MikroTik] ip socks> print
connection-idle-timeout: 2m
max-connections: 200
[admin@MikroTik] ip socks>
Add access to a client with an IP address 192.168.0.2/32 to SOCKS access list, allow data transfer
from FTP server to client (allow destionation ports from 1024 to 65535 for any IP address), and
drop everything else:
[admin@MikroTik] ip socks access> add src-address=192.168.0.2/32 dst-address=:21
action=allow
[admin@MikroTik] ip socks access> add dst-address=:1024-65535 action=allow
[admin@MikroTik] ip socks access> add action=deny
[admin@MikroTik] ip socks access> print
Flags: X - disabled
0 src-address=192.168.0.2/32 dst-address=:21 action=allow
1 dst-address=:1024-65535 action=allow
2 action=deny
[admin@MikroTik] ip socks access>
That's all - the SOCKS server is configured. To see active connections and data transmitted and
received:
[admin@MikroTik] ip socks connections> print
# SRC-ADDRESS
0 192.168.0.2:1238
1 192.168.0.2:1258
[admin@MikroTik] ip socks connections>
Note! In order to use SOCKS proxy server, you have to specify its IP address and port in your FTP
Page 546 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
enabled: yes
port: 1080
DST-ADDRESS
10.5.8.8:21
10.5.8.8:3423
TX RX
1163 4625
0 3231744
