Configuration Reference - MikroTik RouterOS v2.9 Reference Manual

</TR>
<TR>
<TD>ifType:</TD>
</TR>
<TR>
<TD>ifName:</TD>
</TR>
<TR>
<TD>Max Speed:</TD>
</TR>
<TR>
<TD>IP:</TD>
</TR>
</TABLE>
### Queue 'queue1'
Target[RouterBOARD_queue]:
1.3.6.1.4.1.14988.1.1.2.1.1.8.1&1.3.6.1.4.1.14988.1.1.2.1.1.9.1:public@1.1.1.3
#SetEnv[RouterBOARD_queue]: MRTG_INT_IP="1.1.1.3" MRTG_INT_DESCR="ether1"
MaxBytes[RouterBOARD_queue]: 100000
Title[RouterBOARD_queue]: Traffic Analysis for RouterBOARD(1_1)
PageTop[RouterBOARD_queue]: <H1>Traffic Analysis for RouterBOARD(1_1)</H1>
<TABLE>
<TR>
<TD>System:</TD> <TD>RouterBOARD</TD>
</TR>
<TR>
<TD>Maintainer:</TD> <TD>MicroTik Support</TD>
</TR>
<TR>
<TD>Description:</TD><TD>An Embedded Board</TD>
</TR>
<TR>
<TD>ifType:</TD>
</TR>
<TR>
<TD>ifName:</TD>
</TR>
<TR>
<TD>queueName:</TD>
</TR>
<TR>
<TD>Max Speed:</TD>
</TR>
<TR>
<TD>IP:</TD>
</TR>
</TABLE>
The output page of MRTG (interface part) should look like this:
For more information read the MRTG documentation:
Page 410 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
<TD>ethernetCSMACD(6)</TD>
<TD>RemOffice</TD>
<TD>1250.0 kBytes/s</TD>
<TD>10.10.2.1</TD>
<TD>ethernetCSMACD(6)</TD>
<TD>RemOffice</TD>
<TD>queue1</TD>
<TD>64.0 kBytes/s</TD>
<TD>10.10.2.1</TD>

Configuration Reference

Example MRTG Output
