Description
You can install up to four MOXA C502 synchronous cards in one PC box, if you have so many PCI
slots available. Assuming you have all necessary packages and licences installed, in most cases it
should to be done nothing at that point (all drivers are loaded automatically).
Additional Documents
For more information about the MOXA C502 Dual-port Synchronous 8Mb/s Adapter hardware
please see:
• http://www.moxa.com/product/sync/C502.htm
• C502 Dual Port Sync Board User's Manuall

Synchronous Interface Configuration

Home menu level: /interface moxa-c502
Description
Moxa c502 synchronous interface is shown under the interfaces list with the name moxa-c502-N
Property Description
name ( name ; default: moxa-c502-N ) - interface name
cisco-hdlc-keepalive-interval ( time ; default: 10s ) - keepalive period in seconds
clock-rate ( integer ; default: 64000 ) - speed of internal clock
clock-source ( external | internal | tx-from-rx | tx-internal ; default: external ) - clock source
frame-relay-dce ( yes | no ; default: no ) - operate or not in DCE mode
frame-relay-lmi-type ( ansi | ccitt ; default: ansi ) - Frame-relay Local Management Interface type:
• ansi - set LMI type to ANSI-617d (also known as Annex A)
• ccitt - set LMI type to CCITT Q933a (also known as Annex A)
ignore-dcd ( yes | no ; default: no ) - ignore or not DCD
line-protocol ( cisco-hdlc | frame-relay | sync-ppp ; default: sync-ppp ) - line protocol name
mtu ( integer ; default: 1500 ) - Maximum Transmit Unit
Notes
There will be TWO interfaces for each MOXA C502 card since the card has TWO ports.
The MikroTik driver for the MOXA C502 Dual Synchronous adapter allows you to unplug the
V.35 cable from one modem and plug it into another modem with a different clock speed, and you
do not need to restart the interface or router.
