MikroTik RouterOS v2.9 Reference Manual page 268

and this may overload the 3.3V power supply of the board that the card is located on resulting in
voltage drop and reboot or excessive temperatures for the board.
For different versions of Atheros chipset there are different value range of ack-timeout property:
Chipset version
5000 (5.2GHz only)
5211 (802.11a/b)
5212 (802.11a/b/g)
If the wireless interfaces are put in nstreme-dual-slave mode, all configuration will take place in
/interface wireless nstreme-dual submenu, described further on in this manual. In that case,
configuration made in this submenu will be partially ignored. WDS cannot be used together with
the Nstreme-dual.
Example
This example shows how configure a wireless client.
To see current interface settings:
[admin@MikroTik] interface wireless> print
Flags: X - disabled, R - running
0 name="wlan1" mtu=1500 mac-address=00:0B:6B:34:54:FB arp=enabled
disable-running-check=no interface-type=Atheros AR5213
radio-name="000B6B3454FB" mode=station ssid="MikroTik"
frequency-mode=superchannel country=no_country_set antenna-gain=0
frequency=2412 band=2.4ghz-b scan-list=default rate-set=default
supported-rates-b=1Mbps,2Mbps,5.5Mbps,11Mbps
supported-rates-a/g=6Mbps,9Mbps,12Mbps,18Mbps,24Mbps,36Mbps,48Mbps,
basic-rates-b=1Mbps basic-rates-a/g=6Mbps max-station-count=2007
ack-timeout=dynamic tx-power=default tx-power-mode=default
noise-floor-threshold=default periodic-calibration=default
burst-time=disabled fast-frames=no dfs-mode=none antenna-mode=ant-a
wds-mode=disabled wds-default-bridge=none wds-ignore-ssid=no
update-stats-interval=disabled default-authentication=yes
default-forwarding=yes default-ap-tx-limit=0 default-client-tx-limit=0
hide-ssid=no security-profile=default disconnect-timeout=00:00:03
on-fail-retry-time=00:00:00.100 preamble-mode=both
[admin@MikroTik] interface wireless>
Set the ssid to mmt, band to 2.4-b/g and enable the interface. Use the monitor command to see the
connection status.
[admin@MikroTik] interface wireless> set 0 ssid=mmt disabled=no \
band=2.4ghz-b/g
[admin@MikroTik] interface wireless> monitor wlan1
status: connected-to-ess
band: 2.4ghz-g
frequency: 2432MHz
tx-rate: 36Mbps
rx-rate: 36Mbps
ssid: "mmt"
bssid: 00:0B:6B:34:5A:91
radio-name: "000B6B345A91"
signal-strength: -77dBm
tx-signal-strength: -76dBm
tx-ccq: 21%
Page 254 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
5ghz
default max default max default max default max
30 204
30 409
25 409
54Mbps
5ghz-turbo 2ghz-b
22 102 N/A
22 204 109
22 204 30
2ghz-g
N/A N/A N/A
409 N/A N/A
409 52 409
