Winbox; General Information - MikroTik RouterOS v2.9 Reference Manual

Winbox

Document revision 1.0 (Fri Mar 05 07:59:49 GMT 2004)
This document applies to MikroTik RouterOS V2.9
Table of Contents
Table of Contents

General Information

Summary
Description
Troubleshooting
Description
General Information
Summary
The MikroTik RouterOS can be configured remotely, using Telnet, SSH, WinBox Console or
Webbox. In this manual we will discuss how to use the interactive WinBox console.
Description
The Winbox console is used for accessing the MikroTik Router configuration and management
features, using graphical user interface (GUI).
All Winbox interface functions are as close as possible to Console functions: all Winbox functions
are exactly in the same hierarchy in Terminal Console and vice versa (except functions that are not
implemented in Winbox). That is why there are no Winbox sections in the manual.
The Winbox Console plugin loader, the winbox.exe program, can be retrieved from the MikroTik
router, the URL is http://router_address/winbox/winbox.exe Use any web browser on Windows
95/98/ME/NT4.0/2000/XP or Linux to retrieve the winbox.exe executable file from Router. If your
router is not specifically configured, you can also type in the web-browser just
http://router_address
The Winbox plugins are cached on the local disk for each MikroTik RouterOS version. The plugins
are not downloaded, if they are in the cache, and the router has not been upgraded since the last
time it has been accessed.
Starting the Winbox Console
When connecting to the MikroTik router via http (TCP port 80 by default), the router's Welcome
Page is displayed in the web browser:
Page 94 of 695
